Cryogenic Ball Valve LF2 Material 18INCH 600LB API6D
Key Specifications / Features
Model No.: Hits: 5
JONLOO valve company supplies Cryogenic Ball Valve, which is widely used in low temperature and cryogenic applications, including LNG (Liquefied Natural Gas) which is now a better choice of energy.
Request a quote
Share
Tags:
Detail Information
Product Range
-Valve size:
1/2" ~ 24" (DN15-DN600)
-Pressure:
ANSI Class 150~1500(PN16-PN250)
-Temperature:
-196ºC~ 500ºC
-Body Materials:
Stainless Steel, Cryogenic Alloy Steel, Dual-Stainless steel
-Trim(Ball/Seat Ring/Stem):
Stainless, LIPSEAL Seal Ring, Cryogenic resistant with nonmetal seal seat/ring
Technical Specifications
-Design: ASME 16.34/ API 6D
-Face to Face: ASME B16.10
-BW End: ASME B16.25
-Test: API 598/ BS 6755
-Fire Safe Test: API 607/API 6FA
-Special: NACE MR-01-75
Design Features
-Cryogenic Service to -196 C
-Forged or Cast Steel Body
-Floating & Trunnion Mounted Ball
-Extended Bonnet
-Lip Seal
-Cavity Pressure Relief
-Anti-Static Device
-Blow-out Proof Stem
-Fire Safe Design
-In House Cryogenic Testing (On Request)
