Forged Trunnion Mounted Ball Valve 12inch 900LB API6D
Key Specifications / Features
Model No.: Hits: 6
JONLOO company supplies forged Trunnion Mounted Ball Valve. The valve is made of A105N Body , F316 Ball and DEVLON seat. It is designed and manufactured according to API 6D.
Request a quote
Share
Tags:
Detail Information
Details
Size:12 inch
Pressure:900LB
Body/Bonnet:A105
Ball: F316
Stem: 17-4PH
Seat: DEVLON
Worm Gear Operation
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Flanged Ends: ASME B16.5
Test And Inspection: API 598
Features
Reduced port or full port design
Two piece split body or three piece bolted body
With trunnion mounted ball
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
