Globe Type Control Valve With Pneumatic Actuator and Positioner
.jpg?q=80&fm=webp&s=2c8ddd59607c731fac90cf41cd8ac9c6)
Key Specifications / Features
Model No.: Hits: 512
Leading Valve Manufacturer JONLOO supplies Globe Type Control Valve With Pneumatic Actuator and Positioner.
Request a quote
Share
Tags:
Detail Information
The Globe Type Control Valve is a kind of top pilot single seat valve, which has simple structure, good sealing, high flow rate and stable application performance. Reasonable top spiral system can avoid vibration during small opening percentage, so as to extend valve working life.
SPECIFICATION
| Body type: | straight through casting globe type |
| Spool type: | non-balanced single seat plug type |
| Nominal size: | DN20~200 NPS 3/4〞~ 8〞 |
| Nominal pressure: | PN16 ~ 100 CLASS 150LB ~ 600LB |
| Connection: flange: | FF、RF、MF、RTJ |
| Welding: | SW、BW |
| Flange dimension: | acc. To ANSI Standard |
| Bonnet type: | standard type（-5℃~230℃） Radiator type: （-45℃~ high than 230℃ occasion） Low temperature extended type（-196℃~ -45℃） Bellow seal type Warm insulation Jacket type |
| Packing: | V type PFTE packing, flex. graphite packing, etc. |
| Gasket: | Metal graphite packing |
| Actuator: | pneumatic: multi-spring diaphragm actuator, piston type actuator. electric: 3810L series smart actuator, PSL series actuator. |
| Surface painting: | Green color, acrylic acid polythene ceramic paint. |
PERFORMANCE
| Flow Characteristic | Linear, Percentage, Quick Open | ||
| Allowable Range | 50: 1 (CV<6.3 30: 1) | ||
| Rated Cv Value | Percentage CV1.6~630 ，linear CV1.8~690 | ||
| Allowable Leakage | Metal seal: IV grade（0.01% rated capacity） Soft seal: VI grade（foam grade） Leakage standard: GB/T 4213 |
||
| Performance | Pneumatic | Electric | |
| Intrinsic Error % | ±1.5 | ±1.0 | |
| Return Difference, % | ≤1.5 | ≤1.0 | |
| Dead Zone, % | ≤0.6 | ≤1.0 | |
| Difference From Beginning To End Point, % | ±2.5 | ±2.5 | |
| Rated Travel Difference, % | ≤2.5 | ≤2.5 | |
SINGLE SEAT CONTROL VALVE SPECIAL SPECIFICATION
| Special Test | Material Penetration Flaw Detection (PT), Radiator Test (RT), Flow Characteristic Test, Low Temperature Test. |
| Special treatment | Trim nitrogen treatment, seat hard alloy treatment. |
| Special rinse | Degreasing and dehydration treatment |
| Special condition | Special piping or connection, vacuum condition, S.S fastener, special coating. |
| Special dimension | Customized face to face length or dimension |
| Test and inspection | Third party test report |
ACTUATOR
| Type\ Method | Pneumatic Diaphragm Actuator | Electric Actuator |
| ZH23～ZH56 | 3810L Series | |
| Multi-Spring Type | Intelligent Integrated Type | |
| Usage | Regulating type, ON-OFF type | Regulating |
| Air Supply Pressure Or Power Supply Voltage | Air supply pressure (Spring range) 140（20～100）Kpa G 240 (40～200) Kpa G 280 (80～240) Kpa G |
Power: AC 200V±10% 50Hz Or Power: AC 380V±10% 50Hz |
| Connector | Air pipe connector: RC1/4 | Normal type: cable inlet 2-PF(G1/2〞) Explosive proof: Protection jacket PF(G3/4〞) |
| Direct Action | Pressure increase, stem descend, valve close. | Input signal increase, stem descend, valve close. |
| Reaction | Pressure increase, stem ascend, valve open. | Input signal increase, stem ascend, valve open. |
| Input Signal | 40～20mA.DC（with positioner） | Input/output4～20mA.DC |
| Lag | ≤1%FS（with positioner） | ≤0.8%FS |
| Linear Type | 2%FS（with positioner） | ≤+1%FS |
| Environmental Temperature | -10℃～+70℃ | Standard type: -10℃～+60℃ With space heater : -35℃～+60℃ Explosive proof: -10℃～+40℃ |
| Surface Coating | Green, acrylic acid polyurethane coating | Blue, acrylic acid polyurethane coating |
| Accessories | E/P, P/P valve positioner, filter regulator, valve converter, solenoid valve, limited switch | Space heater (normal type) |
