Pneumatic Actuated Ball Valve F304 DN32 PN400 BSP ends
Key Specifications / Features
Model No.: Hits: 77
China ball valve manufacturer JONLOO supplies Pneumatic Actuated Ball Valve at high pressure PN400 with BSP ends.
Request a quote Tags:
Detail Information
Details
High pressure ball valve
Material: F304
Size:DN32
Pressure: PN400
BSP ends
with double acting Pneumatic Actuator
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Flanged End: ASME B16.5
Test And Inspection: API 598
Features
Full port ( FP) or regular bore (RB)
Two piece split body or three piece bolted body
With floating ball design
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
.jpg)
High pressure ball valve
Material: F304
Size:DN32
Pressure: PN400
BSP ends
with double acting Pneumatic Actuator
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Flanged End: ASME B16.5
Test And Inspection: API 598
Features
Full port ( FP) or regular bore (RB)
Two piece split body or three piece bolted body
With floating ball design
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
