Stainless Steel Ball Valve Floating Type 150 LB 6 INCH
Key Specifications / Features
Model No.: Q41F Hits: 157
China ball valve manufacturer JONLOO supplies stainless steel ball valve for corrosive appliaction.
Request a quote
Share
Tags:
Detail Information
Details
Stainless Steel Ball Valve
Size:6inch
Pressure Rating:Class 150LB
Floating Type
Material Body:A351 CF8M
Material Ball:F316
Material Seat:PTFE
Lever operated.
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Flanged End: ASME B16.5
Test And Inspection: API 598
Features
Full port ( FP) or regular bore (RB)
Two piece split body or three piece bolted body
With floating ball design
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
