Trunnion Mounted Ball Valve 600LB WCB Body F316 Ball Nylon Seat
Key Specifications / Features
Model No.: Q347N Hits: 35
JONLOO company supplies Trunnion Mounted Ball Valve with full Bore. The valve is made of A216 WCB Body , A182 F316 Ball and NYLON seat. It is designed and manufactured according to API 6D.
Request a quote
Share
Tags:
Detail Information
Details
Size:16inch
Pressure:600LB
Body/Bonnet:A216 WCB
Ball: A182 F316
Stem: 17-4PH
Seat: NYLON
Full Bore
Worm Gear Operation
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Flanged Ends: ASME B16.5
Test And Inspection: API 598
Features
Reduced port or full port design
Two piece split body or three piece bolted body
With trunnion mounted ball
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
Size:16inch
Pressure:600LB
Body/Bonnet:A216 WCB
Ball: A182 F316
Stem: 17-4PH
Seat: NYLON
Full Bore
Worm Gear Operation
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Flanged Ends: ASME B16.5
Test And Inspection: API 598
Features
Reduced port or full port design
Two piece split body or three piece bolted body
With trunnion mounted ball
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
