3 Inch Gate Valve 300 LB A216 WCB OS&Y Screwed Bonnet
Key Specifications / Features
Model No.: Z41H Hits: 178
Leading Gate Valve supplier Jonloo supplies Gate Valve with OS&Y, Screwed bonnet and flange ends. Bolted Bonnet is also available for the gate valves.
Request a quote
Share
Tags:
Detail Information
Details
Size:3inch
Pressure Rating: Class 300LB
Body/Bonnet: ASTM A216 WCB
Wedge: ASTM A216 WCB
Trim: 1#
Screwed Bonnet
Features
Simple structure, easy operation
Streamline shape, excellent regulation performance
Zero leakage, long service life
Valve disc is connected with stem without pin
Replaceable seat, bi-directional seal
Standards
Design and Manufacture: API 600
Face to Face: ASME B16.10
Flanged Ends : ASME B16.5
Butt Welded Ends: ASME B16.25
Test and Inspection:API 598
