Flanged Ball Valve with lever 4 inch 300 LB
Key Specifications / Features
Model No.: Q41F Hits: 61
China ball valve manufacturer JONLOO supplies Flanged Ball Valve with lever, 4 inch, 300 LB.The valve has 2-piece design.
Request a quote
Share
Tags:
Detail Information
Details
Body/Bonnet: A216 WCB
Ball: F316
Floating Type
Seat: PTFE
Stem: A276 410
Class 300LB
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Butt Welded Ends: ASME B16.25
Test And Inspection: API 598
Features
Full port ( FP) or regular bore (RB)
Two piece split body or three piece bolted body
With floating ball
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
Body/Bonnet: A216 WCB
Ball: F316
Floating Type
Seat: PTFE
Stem: A276 410
Class 300LB
Standards
Design and Manufacture: API 6D
Face To Face: ASME B16.10
Butt Welded Ends: ASME B16.25
Test And Inspection: API 598
Features
Full port ( FP) or regular bore (RB)
Two piece split body or three piece bolted body
With floating ball
Blow-out proof stem, Anti-staic,
Optional locking device or stem extension,
Optional direct mounting to ISO 5211
