Y Type Jacketed Globe Valve
Key Specifications / Features
Model No.: Hits: 13
JONLOO valve company supplies a wide range of jacketed valves, including fully jacketed and half jacketed ones. The Jackets assure consistent valve Heating or Cooling of the process media to prevent crystallization or seizing of flow media.
Request a quote
Share
Tags:
Detail Information
JONLOO supplies a wide range of jacketed valves, including fully jacketed and half jacketed ones.
The Jackets assure consistent valve Heating or Cooling of the process media to prevent crystallization or seizing of flow media. The Jacketed Globe Valve helps the high temperature steam or oil flow over the valve disc & body parts to keep the media liquid. This applies especially to media like bitumen and liquid sulfur. In addition, the efficient flow of media is ensured through the elimination of pockets.
Details
Size:50mm
Pressure Rating: PN40
Body/Bonnet: 304L
Disc: 304L
Seat:STL
gasket: spiral ePTFE (double expanded
with no additives)
handwheel: stainless steel
with screwed-on flanges
Outside screw and yoke
Bolted bonnet
Application:ammonium nitrate solution max98,9%
Temp ≤ 180°C, P ca. 1 bar
heating medium: water steam T max 200°C P ca. 12 bar
Features
1.Straight patteren body design
2.OS & Y,outside screw and yoke
3.BB,Bolted bonnet
4.Yoke intergral with bonnet
5.Rising stem and handwheel
6.Loose disc,choice of plug or ball
7.Renewable seat ring
8.Impact handwheel for 10″ & above
9.Horizontal service
10.Flanged or butt weld ends
11.Available with gear operator
Standards
1.Design and Manufacture: DIN 3356
2.Face to Face: DIN 3202
3.Flanged ends: EN1092-1:2007
4.Inspection and test: API 598
The Jackets assure consistent valve Heating or Cooling of the process media to prevent crystallization or seizing of flow media. The Jacketed Globe Valve helps the high temperature steam or oil flow over the valve disc & body parts to keep the media liquid. This applies especially to media like bitumen and liquid sulfur. In addition, the efficient flow of media is ensured through the elimination of pockets.
Details
Size:50mm
Pressure Rating: PN40
Body/Bonnet: 304L
Disc: 304L
Seat:STL
gasket: spiral ePTFE (double expanded
with no additives)
handwheel: stainless steel
with screwed-on flanges
Outside screw and yoke
Bolted bonnet
Application:ammonium nitrate solution max98,9%
Temp ≤ 180°C, P ca. 1 bar
heating medium: water steam T max 200°C P ca. 12 bar
Features
1.Straight patteren body design
2.OS & Y,outside screw and yoke
3.BB,Bolted bonnet
4.Yoke intergral with bonnet
5.Rising stem and handwheel
6.Loose disc,choice of plug or ball
7.Renewable seat ring
8.Impact handwheel for 10″ & above
9.Horizontal service
10.Flanged or butt weld ends
11.Available with gear operator
Standards
1.Design and Manufacture: DIN 3356
2.Face to Face: DIN 3202
3.Flanged ends: EN1092-1:2007
4.Inspection and test: API 598
