Y-pattern Type Globe valve With Expanded Teflon Gaskets PN40 DN40
Key Specifications / Features
Model No.: Hits: 24
Leading Globe Valve Manufacturer JONLOO supplies Flanged Globe Valve Y-pattern, with expanded pure teflon for packing and body gasket material, which can be used for max 200℃
Request a quote
Share
Tags:
Detail Information
Flanged globe valve Y-pattern
with regulating disc
flange drilling as per EN-1092-1
face type C as per EN 1092-1
face to face L=130 mm (serie 1 EN558)
body, disc: F304L
seat and disc: stellit gr.6
body gasket: spiral gasket, expanded pure Teflon (pure)
packing: expanded pure Teflon (pure)
handwheel: stainless steel
full execution - all parts valve stainless steel
Temp ≤ 200°C
with regulating disc
flange drilling as per EN-1092-1
face type C as per EN 1092-1
face to face L=130 mm (serie 1 EN558)
body, disc: F304L
seat and disc: stellit gr.6
body gasket: spiral gasket, expanded pure Teflon (pure)
packing: expanded pure Teflon (pure)
handwheel: stainless steel
full execution - all parts valve stainless steel
Temp ≤ 200°C
